CP12OM

Braccio & Specs: OMRON TM12S | Payload: 12 kg | Sbraccio: 1300 mm
Short Description: Compattezza e precisione per pallettizzazioni veloci su formati medio-piccoli.
Settori: Food & Beverage, Logistic & E-Commerce, Machinery & OEM, Pharma

Palletizer

CP12OM

Product Name

CP12OM

Product Family

Cobot Palletizer

Arm Model

OMRON TM12S

Arm Payload

12 Kg - 26.46 lb

Arm Extension

1300 mm - 51.18 in

Max Pallet Height

1300 mm - 51.18 in

Max Pallet with 7th axes

Not Available

Accuracy

0,3%-5% full scale

Degress of Freedom

6 optional 7

Max Cycle Time

6 - 8 cycle/minute

Machine Interface

Runtime Siemens Unified

End of Arm Tooling Type Standard

Pneumatic / Electric

Code Reader Available

Vision System, Barcode, QR code reader, RFID, BLE

Safety

Fence with light courtain, Safety Scanner

Interlayer

Not Available

Pallet Available

Optional Available Power Supply

230/240 VAC - 50/60 Hz 16A 1P + N

Arm ISO certification

EN ISO 13849-1 (PLd Category 3)
and EN ISO 10218-1

MES Connectivity

OPC UA

Short Description

Compattezza e precisione per pallettizzazioni veloci su formati medio-piccoli.

Market Segments

Food & Beverage ; Logistic & E-Commerce; Machinery & OEM; Pharma; Beauty & Personal Care; Agro Innovation & Vertical Farming

Warranty expiration

12 Months - Extendable to 24 Months
