CP25FA

Braccio & Specs: ABB GoFa 10 | Payload: 10 kg | Sbraccio: 1620 mm
Short Description: Massima agilità per fine linea ultra-compatti e scatole di piccolo formato.
Settori: Food & Beverage, Logistic & E-Commerce, Machinery & OEM

Palletizer

CP25FA

Product Name

CP25FA

Product Family

Cobot Palletizer

Arm Model

FANUC CRX25IA

Arm Payload

25 Kg - 55.12 lb

Arm Extension

1889 mm - 74.37 in

Max Pallet Height

1900 mm - 74.90 in

Max Pallet with 7th axes

2600 mm - non testato / 102.36 in

Accuracy

+ - 0.05 mm / ±0.00197 in

Degress of Freedom

6 optional 7

Max Cycle Time

8 - 10 cycle/minute

Machine Interface

Runtime Siemens Unified

End of Arm Tooling Type Standard

Pneumatic / Electric

Code Reader Available

Vision System, Barcode, QR code reader, RFID, BLE

Safety

Fence with light courtain, Safety Scanner

Interlayer

Optional left and right

Pallet Available

EU / US

Optional Available Power Supply

230/240 VAC - 50/60 Hz 16A 1P + N

Arm ISO certification

EN ISO 13849-1 (PLd Category 3)
and EN ISO 10218-1

MES Connectivity

OPC UA

Short Description

Progettato per cicli continui ad alta intensità con cinematica FA.

Market Segments

Food & Beverage ; Logistic & E-Commerce; Machinery & OEM; Pharma; Beauty & Personal Care; Agro Innovation & Vertical Farming

Warranty expiration

12 Months - Extendable to 24 Months
