CP16JA

Braccio & Specs: JAKA ZU16PRO | Payload: 16 kg | Sbraccio: 1713 mm | Ripetibilità: ± 0,02 mm
Short Description: Il compromesso ideale tra velocità di esecuzione e capacità di carico.
Settori: Food & Beverage, Logistic & E-Commerce, Machinery & OEM, Pharma, Beauty & Personal Care

Palletizer

CP16JA

Product Name

CP16JA

Product Family

Cobot Palletizer

Arm Model

JAKA ZU16PRO

Arm Payload

16 Kg - 35.27 lb

Arm Extension

1713 mm - 67.44 in

Max Pallet Height

1700 mm 66.93 in

Max Pallet with 7th axes

2400 mm - 94.49 in

Accuracy

'+ - 0.03 mm / ±0.00118 in

Degress of Freedom

6 optional 7

Max Cycle Time

8 - 10 cycle/minute

Machine Interface

Runtime Siemens Unified

End of Arm Tooling Type Standard

Pneumatic / Electric

Code Reader Available

Vision System, Barcode, QR code reader, RFID, BLE

Safety

Fence with light courtain, Safety Scanner

Interlayer

Optional left and right

Pallet Available

EU / US

Optional Available Power Supply

230/240 VAC - 50/60 Hz 16A 1P + N

MES Connectivity

OPC UA

Short Description

Il compromesso ideale tra velocità di esecuzione e capacità di carico.

Market Segments

Food & Beverage ; Logistic & E-Commerce; Machinery & OEM; Pharma; Beauty & Personal Care; Agro Innovation & Vertical Farming

Warranty expiration

12 Months - Extendable to 24 Months
